Cobalt 2000 Laser Plate-Maker

Most economical WFC Laser printing plate maker – for production volumes corresponding to 1-5 pad printers

Price: Under $8,000

Laser Type - Details

WFC technology – Patent pending

Max. Marking Area

390mm X 173mm (15.4″ X 8.3″)

Max. Plate Size

400mm X 300mm (15.75″ x 11.8″)

Spot Size

Ultra-fine spot size: 20 microns

Current/Voltage

100-240 VAC. 1 Phase / 50-60 Hz 1.6 Amp

Operation Controls
  • Magnetic hold-down plate load/unload tray
  • Class 1 laser enclosure
  • Interlocked safety doors
Software

Cobalt 2000 RIP software package

Life Expectancy

20,000 hours

Warranty

InkcupCare warranty – 1 year

FEATURES COMMON TO ALL INKCUPS LASERS
  • Adjustable power, frequency and speed settings
  • Ventilation port for RX-4 exhaust
  • Integrated exhaust control – automatically turns off with laser
  • Network connectivity
  • Industrial grade construction – U.S. Made
  • Overview

    Most economical WFC Laser printing plate maker – for production volumes corresponding to 1-5 pad printers

    Price: Under $8,000

  • Specifications
    Laser Type - Details

    WFC technology – Patent pending

    Max. Marking Area

    390mm X 173mm (15.4″ X 8.3″)

    Max. Plate Size

    400mm X 300mm (15.75″ x 11.8″)

    Spot Size

    Ultra-fine spot size: 20 microns

    Current/Voltage

    100-240 VAC. 1 Phase / 50-60 Hz 1.6 Amp

    Operation Controls
    • Magnetic hold-down plate load/unload tray
    • Class 1 laser enclosure
    • Interlocked safety doors
    Software

    Cobalt 2000 RIP software package

    Life Expectancy

    20,000 hours

    Warranty

    InkcupCare warranty – 1 year

    FEATURES COMMON TO ALL INKCUPS LASERS
    • Adjustable power, frequency and speed settings
    • Ventilation port for RX-4 exhaust
    • Integrated exhaust control – automatically turns off with laser
    • Network connectivity
    • Industrial grade construction – U.S. Made
